Standard laboratory glassware & products for the Petroleum and Chemical Industries
| Glassware for petroluem and checmical products | ||
| Name | Standard | Specification |
| Distillation cylinder | ASTM D86 | 5,10,100ml |
| Distillation flask | ASTM D86 | 100,125ml |
| Gasoline induction period oil cup | ASTM D525 | |
| Mercury pressure meter | ASTM D323 | 0～800mm |
| Water content tester | ASTM D95 | Round bottm flask(500ml),reciever,condensing pipe |
| Aniline point test tube | ASTM D611 | Internal, external test tube |
| Aniline point U tube | ASTM D611 | 22.5～23.0ml |
| Engler viscometer receiving bottle | ASTM D1665 | Receiving bottle(200ml), Receiving bottle(100ml) |
| Sulfur content tester | ASTM D1266 | Reciever,Drop collector,Smoke flue,Combustion lamp |
| Sulfur content combustion tube | ASTM D1551 | Quartz bend, ground quartz tube |
| Corrosion degree test tube | GB/T391 | |
| Gum cup | GB/T509 | 100ml |
| Condensation point test tube | ASTM D97 | Internal, external test tube |
| Solidification point test tube (ground port) | ASTM D97 | Internal, external test tube |
| Water reaction cylinder | ASTM D1094 | 100ml |
| Aromatic hydrocarbons acid wash comparison tube | ISO 5274 | |
| Freezing point test tube | ISO 3013 | Double wall glass test tube, A-moistureproof tube, B-moistureproof tube |
| Wax melting point test tube, water bath tank | ISO 3841 | Water bath tank, melting point test tube |
| Density bottle | GB/T2540 | Ground plug type. Capillary plug type, wide-mouth type |
| Benzene crystallization point test tube | SH/T0090 | Internal, external test tube |
| Benzenes distillation range tester | ASTM D1078 | Distillation flask(150ml), single tube fractionating tube， condensing tubeoxhorn tube,Reducing cylinder(100ml) |
| Wide range dropping point test tube | ASTM D2265 | |
| Pour point, Cloud point test tube | ASTM D97 ASTM D2500 GB/T7326 | Internal, external test tube |
| Wax content tester | ASTM D721 SH/T0556 | Tubular immersion filter, test tube, pipetting liquid, taper weighing bottle |
| Saybolt comparison tube | ASTM D156 | Sample tube, standard color scale glass tube |
| Dropping point test tube | ASTM D566 | |
| Bitumen brittle point | IP 80 | Internal, external test tube |
| Copper strip corrosion, viewing test tube | ASTM D130 | Corrosion tube, viewing tube |
| Extracter | ASTM D6470 GB/T6535 | Flask(500ml),condenser,column dropping funnel |
| Centrifuge tube | ASTM D4007 ASTM D893 ASTM D1837 SH/T0125 SH/T0024 SH/T0037 | 100ml |
| Gas & Liquid buret | ASTM D2533 | |
| Color comparation tube | ASTM D1500 SH/T0168 | |
| Emulsion resistance cylinder | ASTM D1401 | 100ml (with base, without base) |
| Distillation and adsorption device | GB/T7363 | Rectifying column, distillation flask (2000ml), ground plug, Corner condenser, reciever (1000ml), vessel(500ml), chromatographic column(500ml), straight condenser, distillation flask(250, 500ml), flask plug |
| Comparison tube | ASTM D612 | 16ml |
| Gasoline oxidation stability oil cup | ASTM D525 | |
| Gum cup | ASTM D381 | 100ml |
| Demulsibility open separating funnel | ASTM D2711 | 500ml |
| Glass tube for ball viscometer | GB/T8030 | |
| Curde oil water content tester | ASTM D4006 | Drying pipe, condensing pipe, reciever, round bottom flask (1000ml) |
| Vacuum distillation apparatus | ASTM D1160 | Distillation flask(500ml), vacuum jacket distillation column assembly, reciever |
| Lampshade | ASTM D187 | |
| Sulfur content tester | GB/T11131 | Reciever, fogdrop reciever, lampshade, standard flask, burner |
| Fluorescent color layer capillary adsorption column | ASTM D1319 | Precision inner diameter adsorption column, standard adsorption column |
| Flask for corrosion | ASTM D665 | 400ml |
| Ground plate bottom glass tube | ASTM D2983 | Internal, external test tube |
| Total acid value titration bottle | GB/T12574 | 500ml |
| Floc point tube | DIN 51351 | bolck type, melt sealing |
| U tube | GB/T12578 | |
| Foam character cylinder | ASTM D892 | 1000ml(with base, without base ) |
| Constant temperature glass tank | ASTM D892 | |
| Turbine oil oxidation tester | ASTM D943 SH/T0175 SH/T0565 | Test tube, oxidation conduct, condensing tube |
| Aging test tube | DIN 51352 | Internal, external test tube |
| Density bottle | ISO 3838 | 10, 25, 50ml crash helmet pycnometer, Gay-Lussac pycnometer , wide mouth pycnometer |
| Density bottle | ISO 3838 | 1, 2, 5, 10ml |
| Hydrogen content tester | SH/T0022 | Lamp bottle(25ml), lamp lid, burner,flue,receiving bottle,Taper chamber |
| Silver strip corrosion tester | SH/T0023 | Test tube,condenser,glass hook |
| Centrifuge tube | SH/T0057 | 100ml |
| Gasoline and paroline depentanizer dephlegmator | SH/T0062 | Distillation bottle,(100ml),Distillation column,reflux condenser, light distillate collector,oil resistance rubber plug, reciever(15ml) |
| Particulate pollutant test container | 1000ml | |
| Coolant corrosion tester | SH/T0085 | Gas diffusion tube,reflux condesing tube,no mouth high type flask(1000ml) |
| Boiling point tester | SH/T0089 | Double port flask(100ml), condensing pipe |
| Extracter | SH/T0097 | Flat bottom flask(1000ml) extracting pipe, five balls cooler, unbrella tube |
| Emulsify bitumen cylinder | SH/T0099.5 | 250ml |
| Test tube | SH/T0104 | |
| Flask, test tube, grease cup for dropping point | SH/T0115 | Flask, test tube, grease cup |
| Gear oil oxidation tube | SH/T0123 | oxidation tube, glass air pipe |
| Lube oil oxidation pipe | SH/T0124 SH/T01875 | |
| Soap film flowmeter | SH/T0124 | 50, 25, 100, 200, 250, 1000ml |
| Arsenic test device | SH/T0130 | Generator (60ml), glass exhaust pipe, brown glass pipe |
| Carbon residue tester | SH/T0160 | Distillation bottle,(250ml), Cylinder (200ml), glass coking bottle, sampling pipe |
| Vacuum Distillation Range Tester | SH/T0165 | Distillation bottle(250ml), receiving bottle(100ml), Doble are pressure gauge |
| Molecular weight test tube | SH/T0169 | Internal, external test tube |
| Crystallization point double wall glass tube | SH/T0179 | Internal, external test tube |
| Demulsibility value tester | SH/T0191 | Graduated cylinder(50ml), bend tube (4 types),Beaker without mouth(3000ml), Shrot radius flask(1000ml) |
| RBOT glass container | SH/T0193 | 175ml |
| Lube oil antioxidation stability tester | SH/T0196 | Oxidation , adsorption bottle |
| Transformer oil oxidation tube | SH/T0206 | |
| Aviation hydraulic fluid oxidation stability tester | SH/T0208 | 5 ball condensing pipe, oxidation pipe, bottle plug |
| Thermal oxidation pipe | SH/T0219 | Test tube, Air blow in tube, Blow off pipe |
| Diesel stability tester | SH/T0238 | Flask (1000ml), condensing pipe |
| Aviation fuel stability oil cup | SH/T0241 | |
| Congealing point tester | SH/T0248 | Test cup,pipet,U manometer, pressure regulation water tank |
| Thermal oxidation stability tester for fuel oil | SH/T0250 | Heating pipe, cooling pipe |
| Micro sulfur tester | SH/T0252 | Reaction flask, Acid tap funnel, Reciever |
| Cylinder for demulsibility time, flask | SH/T0256 | Cylinder (250ml), Flask(1000ml) |
| Asphaltene extracter | SH/T0266 | Flask (500ml), Ball type condensing pipe, Extracter |
| Vacuum oil saturated vapor pressure swing device | SH/T0293 | |
| Oxidation water solubility tester | SH/T0295 | Oxidation pipe, Volatility water Soluble acid absorber |
| Internal combustion engine oil oxidation pipe | SH/T0299 | Oxidation pipe, oxygen feed tube |
| Release value heat resistance jacket glass tube | SH/T0308 | |
| Petroleum coke density bottle | SH/T0313 | 25,50,100ml |
| Bitumen wax content tester | SH/T0425 | Glass pyrolysis distillation flask, glass shield, cooling bath tank, filter flask, sample cooling tube, Plunger rod, glass filtering funnel, Conical flask |
| Boling point tester | SH/T0430 | Flask（100ml）, Condensing pipe |
| Rubber consistency glass oil cup | SH/T0436 | |
| Synthetic oil oxidation corrosion tester | SH/T0450 | Oxidation pipe, air feed pipe, condensing pipe |
| Cylinder with plug | SH/T0568 SH/T0569 | 100ml |
| Oil content tester | SH/T0580 | 115ml |
| Cylinder without mouth | SH/T0588 | 100ml |
| Chromatographic column | SH/T0606 | |
| Hargil silicone adsorption column | SH/T0607 | Upper column-hargil adsorption column, Lower column-hargil silicone adsorption column |
| Extraction device | SH/T0608 | Flat bottom flask with three ports(500ml), Separation column, shunt condenser |
| Azobenzene adsorption column | SH/T0609 | Gas bottle, Liquid bottle（125ml）, manometer |
